TS166M-9BB

TS Solar Energy Co., Ltd.
Type Cellule: PERC
Gamme de Puissance: 5,89~6,28 Wp
Région: Thaïlande Thaïlande
Contacter le Fabricant
Remarque: Votre demande sera envoyée directement à TS Solar Energy Co., Ltd..

Description:

  • High-purity monocrystalline technology combined with PERC, multi-busbar, large cell design, and robust parts

  • 166mm 9BB solar cells pack more power, capture more photons, produce more energy, and provide reliable performance

  • Each cell features 124 grid fingers connected to 9BB

  • Power output of 6.28W per cell at 22.9% efficiency

Caractéristiques du Produit

No. de Modèle
5,89 5,92 5,95 5,98 6 6,03 6,06 6,09 6,11 6,14 6,17 6,20 6,22 6,25 6,28
Caractéristiques du Produit
Type de cellules PERC
Dimension 166×166 mm
Epaisseur de la cellule 190 ± 30 µm
Face avant (-)
No. de bus bars 9
Largeur des bus bars 0,1±0,03 mm
Matériau des bus bars Argent
Traitement Antireflet Nitrure de silicium
Face arrière (+)
Nombre de zone de soudure 9
Largeur la de Zone de Soudure 1,3±0,25 mm
Matière la de zone de soudure Argent
Champ de surface arrière (BSF) (BSF) Aluminium
Caractéstique Electrique (STC)
Puissance Maximal (Pmax)
5,89 W 5,92 W 5,95 W 5,98 W 6 W 6,03 W 6,06 W 6,09 W 6,11 W 6,14 W 6,17 W 6,2 W 6,22 W 6,25 W 6,28 W
Tension à Puissance Maximal (Vmpp)
0,5684 V 0,5701 V 0,572 V 0,5742 V 0,576 V 0,5781 V 0,5799 V 0,5817 V 0,5835 V 0,5856 V 0,5873 V 0,5887 V 0,5905 V 0,5916 V 0,5933 V
Courant à Puissance Maximum (Impp)
10,371 A 10,386 A 10,401 A 10,409 A 10,424 A 10,433 A 10,448 A 10,462 A 10,477 A 10,486 A 10,503 A 10,525 A 10,54 A 10,566 A 10,582 A
Tension Circuit Ouvert (Voc)
0,6713 V 0,6719 V 0,6729 V 0,6743 V 0,6748 V 0,6774 V 0,6777 V 0,678 V 0,679 V 0,6807 V 0,6811 V 0,6822 V 0,6837 V 0,6859 V 0,6874 V
Courant Circuit Court (Isc)
10,958 A 10,974 A 10,99 A 10,996 A 11,014 A 11,021 A 11,039 A 11,046 A 11,06 A 11,075 A 11,082 A 11,09 A 11,105 A 11,1 A 11,113 A
Efficacité de la Cellule
21,5 % 21,6 % 21,7 % 21,8 % 21,9 % 22 % 22,1 % 22,2 % 22,3 % 22,4 % 22,5 % 22,6 % 22,7 % 22,8 % 22,9 %
Facteur de remplissage (FF)
80,12 % 80,3 % 80,45 % 80,6 % 80,79 % 80,81 % 80,98 % 81,26 % 81,41 % 81,46 % 81,73 % 81,89 % 81,97 % 82,1 % 82,18 %
Caractéristique de Température
Coefficient Température (Pmax) -0,38 %/˚C
Coefficient Température (Voc) -0,36 %/˚C
Coefficient Température (lsc) 0,07 %/˚C
Dépendance de l’intensité
Intensité
Voc
Vmpp
1000 W/m2
1
--
900 W/m2
0,996
--
800 W/m2
0,991
--
600 W/m2
0,988
--
400 W/m2
0,962
--
